Weld 5-Way Cross

Part Number: G-10W-400-B

  • Contact us at 800-824-4166 to find out about Nor-Cal's custom weldment offerings
  • Fittings with extended tangents ideal for orbital welders
  • Use wled fittings and tubing to create unique pump line geometries
4" OD 5-Way Cross, Beadblast Finish
Technical Resources
  • Tube OD: 4"
  • Cross Type: 5-Way
  • Material: 304 Stainless
  • Port Length: 3.88"
  • Wall Thickness: 0.083"
  • Finish: Bead Blast
  • Vacuum Range: 1 · 10-13 mbar to 1 bar
  • Temperature Range: -200 °C to 450 °C
  • Weight: 3.1 lbs
Imperial Units
Dim A: 3.88"
Dim C: 0.083"
