BNC Instrumentation Feedthrough

Part Number: BNC-150-3
Price: $260.00
Quantity:

2.75" OD CF Coaxial Feedthrough, 3 Feedthroughs
Technical Resources
Specifications
  • Feedthrough Type: Instrumentation
  • Flange Size / Type: DN 40 CF (2.75" OD)
  • # Feedthroughs: Three
  • Pin Material: Stainless Steel
  • Flange Material: 304 Stainless
  • Vacuum Range: 1 · 10-10 mbar to 1 bar (UHV)
  • Temperature Range: |-270 °C to 450 °C
  • Voltage Rating: 00 V DC
  • Current Rating: A
  • Electrical Connector: NC-VC
  • Weight: .5 lbs
Coaxial-Feedthroughs-Dia
Imperial Units
Dim A: .38"
Dim B: .370"
Dim C: .950"
