Throttling Pendulum Valve, Analog/TTL Controller

Part Number: BQC-800L-A
Quantity:


Features
  • Adaptive algorithm for improved stability and faster transitions
  • CE marked/fully REACH and RoHS compliant
CONTROLLER,TPV,ANLG,24VDC
Technical Resources
Specifications
  • Valve / Flange Size: DN 150 to DN 350
  • Communications Interface: Analog
  • Additional Controller Features: none
  • Controller Communications: Analog/TTL system interface; RS232 service port
  • Supply Voltage: 24 V DC (±5 %)
  • Power Connector: |XLR, 5-pin, Female
  • Gauge Power Supply: |±15 V DC (±5%), 1.4 A max.
  • Power Fail Option: ot included
  • Temp. Limits (actuator): °C (minimum), 45 °C (maximum)
  • Material (valve body): 2 Aluminum
  • Weight: 4 lbs
BQC_dimension_drawing
Imperial Units
Dim A: 9"
Dim B: 3"
Dim C: 6"
Dim D: 7"
Dim E: 6"
